SB Series CNC Hydraulic Pipe Bending Machine
Listing time: April 2026
Bending: Φ50×3mm, R250,190°
Drive Type: Servo‑hydraulic hybrid
Total Power: 10.75kW
Screen size: 10‑inch industrial touch screen
Category：Pipe bending machine
Product Details
Mechanical characteristics
■ Machine is beautiful and delicate,and provides the space for the biggest bending pipe.
■ Adopting single chip microcomputer control, easy to operate.
■ The angle of bending uses encoder tracking and give a feedback with a high bending precision.
■ Storaging of multiple sets of processing mode,flexible switching between different specifications.
■ With automatic counting and power-off memory function.
■ Equipped with hydraulic cooling system to ensure the stability of the machine.
Machine parameters
Products Description
| OD(Inch) | OD(mm) | WT(mm) | Mandrel Length(mm) | Push bending | Model |
| 1/3 | 8 | Wire | – | ✓ | WB-8CNC-5A-3D |
| 2/5 | 10 | WB-10CNC-5A-3D | |||
| 1/2 | 12 | WB-12CNC-5A-3D | |||
| 5/9 | 14 | WB-14CNC-5A-3D | |||
| 5/7 | 18 | 1.5 | 2000 | Option | SB-18CNC |
| 1 | 25 | 2.0 | 2500 | Option | SB-25NCBSB-25CNC |
| 1 1/2 | 38 | 3.0 | 3500 | Option | SB-38NCBSB-38CNC |
| 2 | 50 | 3.0 | 3800 | Option | SB-50NCBSB-50CNC |
| 2 1/2 | 65 | 4.0 | 4000 | Option | SB-65NCBSB-65CNC |
| 3 | 75 | 4.0 | 4200 | Option | SB-75NCBSB-75CNC |
| 3 1/2 | 89 | 4.0 | 4500 | Option | SB-89NCBSB-89CNC |
| 4 | 100 | 5.0 | 4500 | Option | SB-100NCBSB-100CNC |
| 4 1/2 | 120 | 6.5 | 6000 | Option | SB-120NCBSB-120CNC |
| 5 | 130 | 6.5 | 6000 | Option | SB-130NCBSB-130CNC |
| 6 1/2 | 168 | 10.0 | Custom-made | Option | SB-168NCBSB-168CNC |
| 7 1/2 | 189 | 10.0 | Custom-made | Option | SB-189NCBSB-189CNC |
| 8 1/2 | 219 | 20.0 | Custom-made | – | SB-219NCBSB-219CNC |
| 12 1/2 | 325 | 20.0 | Custom-made | – | SB-325NCBSB-325CNC |
| 12 1/2 | 325 (Heat Bend) | 20.0 | Custom-made | – | IB-325 |
| 16 1/2 | 426 (Heat Bend) | 20.0 | Custom-made | – | IB-426 |
Frequently Asked Questions
Our CNC pipe benders, tube cutting machines and tube end forming machines process carbon steel, stainless steel, aluminum and copper. They handle round, square and rectangular tubes for furniture, auto parts and engineering machinery industries.
We offer customized machines based on tube specifications, bending angles, forming processes and automation levels. Multi-station composite functions are available to fit your exclusive production workflow.
All CNC models adopt intelligent control systems with easy program storage. Stable repeat machining accuracy reduces reject rates, ideal for mass continuous production.
We design fully automatic pipe processing lines integrating cutting, end forming and bending. Seamless process connection cuts labor costs and improves overall production capacity.
CNC pipe benders enable one-step multi-angle forming and small-radius bending. They avoid tube wrinkling and collapse, suitable for complex special-shaped pipe workpieces.
Tube cutting machines deliver flat, burr-free cutting surfaces. Tube end formers support flaring, shrinking, bulging and other end processes, enabling multiple pipe end forming operations on a single machine。
